Water Leakage Monitoring and Alarm Unit

NX-02 water leak controller can detect 1500m sensing cable. It’ll alarm by
flash and sound once there are water leaks on the cable, and the leakage
point will display on the LCD screen and the relays will be on

Combined with the MOD BUS RTU protocol, NX-02 makes it easy to integrate with the monitoring system. NX-02 can be used as an independent alarm, also can be connected to another monitoring system. It’s widely used in the monitoring data centers,machine rooms, warehouses, museums, industrial, fields to realize real-time leakage detecting.



AC/DC 9~24V power supply

Easy guide rail installation

32 leakage records can be kept

Relay outputting and NO/NC can be choose

Leakage point and cable error will display on the nixie tube

Baud rate and module can be set on the software, no switch

Super anti-static, anti-lighting, and anti-surge to make sure the operation

Twisted-paired cable with RS-485 serial communication, standard Modbus protocol, the furthest communication can reach 1200m

Power, leakage, cable error, and communication status display on the LCD screen
